FA1013NP-H/Y
10.1" LCD Camera Monitor With HDMI & YPBPR & AV input
FA1013NP-H/Y/S
10.1" LCD Camera Monitor With 3G-SDI & HDMI & YPBPR & AV input,3G-SDI output.
Functions:
3G-SDI、HDMI & YPbPr Input, to connect with Full HD Video Camera
LCD 16:9 Aspect Ratio, max 1920×1080 pixels
To connect with Full HD Video Camera, as sub-monitor when CCTV Monitoring or Making Movies
Multi mounting methods to view under different angles
Parameters:
Panel Size: 10.1" TFT LCD (16:9)
Resolution: 1024×600, support up to 1920×1080
Brightness: 250cd/㎡
Contrast: 500:1
Viewing Angle: 140°/ 110°(H/V)
Input Voltage: DC 12V (XLR DC Connection)
Input Signal: 3G-SDI, HDMI,YPbPr, AV1/AV2
SDI/HDMI/YPbPr Mode: 480i/p、576i/p、720p、1080i(50/60)、1080p(50/60)
Color System: PAL / NTSC
Current: 500mA (under 800*600-60Hz)
Standby Current: ≤50mA
Power Consumption: ≤6W
Audio Output: ≥250mW
Speaker: ×1(back)
Ear Phone Slot: ×1
Mounts Process: Standard VESA (75mm) Sockets
Size:(LWD): 259 x 170 x 36.5mm
Weight: 1144g
Accessories:
DC adapter
Remote control
Manual
HDMI to mini HDMI cable (optional)
VESA 75mm rail slot (optional)
